25
Alternating Current (AC) connection
Be sure any electric devices are turned off before plugging them in.
z Be sure all electric devices including the lines
and plug connections are in good condition
before connection to the generator.
z Be sure the total load is within generator rated
output.
z Be sure the receptacle load current is within
receptacle rated current.
TIP：Make sure to ground (Earth) the generator.
When the electric device is earthed, always the generator must be earthed.
1. Sart the engine.
2. Turn the ESC to “ON”.
3. Plug in to AC receptacle.
4. Make sure the AC pilot light is on.
5. Turn on any electric devices
TIP：The ESC must be turned to “OFF” to increase engine speed to rated rpm.
If the generator is connected to multiple loads or electricity consumers, please
remember to first connect the one with the highest starting current.. and last
connect the one with the lowest starting current.
Battery Charging
TIP
· The generator DC rated voltage is 12V.
· Start the engine first, and then connect the
generator to the battery for charging.
· Before starting to charge the battery, make sure
t hat the DC protector is turned on.
1. Start the engine.
2. Connect the red battery charger lead to the
positive (+) battery terminal.
To Next Page
