29
Application range
When using the generator, make sure the total load is within rated output of a
generator. Otherwise, generator damage may occur
AC
Power
factor
1 0.8-0.95
0.4-0.75
(Efficiency 0.85)
LC2000i ~1,600W ~1,280W ~544W
Rated voltage 12v
Rated current8.3A
TIP
· “~”means below.
· Application wattage indicates when each device is used by itself.
· The simultaneous usage of AC and DC power is possible but total wattage
should not exceed the rated output.
EX:
Generator rated output 1,600VA
Frequency Power factor
1.0 ～1,600W
AC
0.8 ～1,280W
DC ---
100W
(12V/8.3A)
The overload indicator light comes on when total wattage exceeds the
application range. (See page 14 for more details.)
