SECTION 4. DISASSEMBLY AND SERVICE
4-3 Disassembly Chart
This chart is a quick-reference guide for
disassembling the product. Be sure to follow
the sequence shown here for better and safer
work.
GENERATOR DISASSEMBLY
MUFFLER
LEFT AND RIGHT
CARRYING HANDLES
LOUVER
CONTROL PANEL
PANEL BED
STATOR
ROTOR
MOUNT RUBBER
FRAME BEDPLATE
MAIN UNIT BUFFER
PAD
INVERTER
BRACKET
AIR CLEANER
CARBURETOR
RECOIL STARTER
FAN COVER
FLYWHEEL
MOTOR REAR
SUPPOER
ENGINE
FUEL TANK
