LONCIN LC2000i User Manual

SECTION 4. DISASSEMBLY AND SERVICE
b. DISASSEMBLY/ REASSEMBLY
PUSH ROD
REASSEMBLY:
Check both ends for wear, check rod
for straightness. T
hen insert it
through cylinder head and
crankcase’
s valve lifter hole, and
install it into the proper place.
INTAKE
VALVE
REASSEMBLY:
Do not interchange with
the exhaust valve.
Be careful not to damage
valve stem.
EXHAUST
VALVE
REASSEMBLY:
Check valve face for
damage and carbon
deposit, then install.
SPARK PLUG
REASSEMBLY:
Clean and adjust spark
plug before reinstalling it
Torque: 25-28 N·m
VALVE STEM
SEAL
VALVE
SPRING
ROCKER ARM
SHAFT
VALVE
KEEPER
ROCKER ARM
REASSEMBLY:
Before installing, check for
wear on surface where
central hole contacting
the
push rod
ROCKER ARM
PIVOT BOLT
REASSEMBLY:
Before installing, check
for wear on the surface
contacting the valve.
PIVOT LOCK
NUT
VALVE SPRING
RETAINER
- 28 -
