Adjustment of throttle cable
1. Confirm the normal work of adjustment nut for throttle cable.
2. Confirm the free travel of throttle turning grip during normal range.
3. Stipulated free travel: 6mm in case not, adjust by its nut.２～ ，
After throttle cable is adjusted check turning performance of grip. No higher engine idling speed dueto
adjustment is allowed, meanwhile, grip should turn off automaticall
，
y.
20
1. Carburetor for models passed StateIII standard was carefully adjusted.
2. Idling adjustment of engine should be under hot status.
3. Lay the motorcycle on flat ground, and adjust by idling screw.Idling
speed 1500±150r/min ：
Engine's idling adjustment should be under the situation of sufficient pre-heating.
Adjustment of carburetor
Warning:
Warning:
Locking nut Adjustment nut
Idle bolt
