5.5 Wiring of the sockets
5pin XLR (DMX):
Pin 1 = Ground, Pin 2 = DMX –, Pin 3 = DMX +
3pin XLR (analog):
Pin 1 = Ground, Pin 2 = 0-10 V + DC in, Pin 3 = 12 V + DC out, max. 50 mA
5.4.5.1 Auto start
If the timer is in operation and you unplug the machine from the power outlet,
the Unique
2
will re-start in the Timer-Mode as soon as it‘s reconnected. To stop
this press the Mode button [14] for more than 2 Seconds or by switching to „ESC“
in the Timer-Mode and then press the Enter button.
Please note that if you disconnect the power to the machine during the haze/
fog time, then a bit of wet residue will be blown from the heater when the
machine is first turned on again, so disconnect the machine during a pause time
instead of a fog time if possible. To avoid any possibility of residue, use the
shutdown procedure in section 5.3 and do not use Auto start.
5. Operating the Unique
2
With the internal timer, the haze time and wait time can be adjusted in Minutes
(0.1 - 99), the pump and fan output can be adjusted in per cent (0 - 99).
To start the Timer-Mode, press and hold the Mode button [16] for more than 2
Seconds. The red Timer/Profile-LED [19] will blink as soon as the machine has
switched to the Timer-Mode. As long as the timer is in operation, the red Timer/
Profile-LED blinks.
The adjusting of the output, haze time or wait time is the same as in the Stan-
dard-Menu. This means you have to press the Mode button repeatedly until you
reach the required function.
With the Up/Down buttons you can adjust the required functions, then press
the Enter button to start the timer. Please note that P and F control Pump and
Fan, whereas P. and F. control Pause time and Haze (Fog) time (Figs. 10 - 13).
The timer cycle starts with the time shown on the display when you press the
Enter button (i. e. P.xx = Starts with wait time, F.xx = Starts with haze time). The
timer cycle will not start if you press the Enter button while the pump or fan
output setting is shown on the display.
You can switch back to the Standard-Menu by pressing the Mode button [14]
for more than 2 Seconds or by pressing the Mode button repeatedly until „ESC“
shows on the display and then press the Enter button once.
