6
3
1
4
5
230 V~/50Hz/1500W
Made by OTTEC Technology GmbH for
Look
- Solutions made in Germany
analog in dmx
512
Serial no.
This machine has been designed to be used with original Look Unique-fluid.
Use of other liquids will void the manufacturer's warranty and can be
dangerous to your health. Never use cleaner or fragrances with this
machine!
P 2 5
Rear view
2
6
Front view
7: · Nozzle
Vap ou r and nozzl e area
extremely hot. Do not touch!
Do not cover the nozzle area
and do not connect a ducting!
3. Description of the parts
1: · Power cable
2: · XLR sockets for DMX in/out
3: · XLR socket for 0-10 V (+) DC
4: · Fluid tube inlet
5: · Fluid tube
6: · Control panel for adjusting
the DMX start address and
the output
