Machine elements
- 5 -02.20 909.2710.1-06
Fig. 2: Machine element S/P mobile
1 Connection socket ground cable
2 Ground cable
3 Connection socket electrode holder
4 Air intake
5 Socket remote control (optional)
6 Coolant filling nozzle (optional)
7 Coolant return (optional)
8 Coolant flow (optional)
9 Torch socket/digital push pull (optional)
10 LorchNet socket
11 Central socket
12 TIG torch socket control line (optional)
13 TIG torch gas connection (optional)
14 Hand grip
15 Display welding current/voltage indicator
16 Control panel
17 Hoisting points
18 Protective cover, operating console (option
-
al)
19 Torch
20 Pressure reducer
21 Gas bottle
1)
1)
Accessories
22 Gas hose
23 Chain
24 Tray area
25 Mains plug
26 Ground clamp
27 Main switch
28 Transport rollers
29 Socket for WUK 5 cooling system
Some depicted or described accesso
ies are not included in the scope of de
-
livery. Subject to change.
1 2928
17
18
22
16
15
14
13
12
1059
311
27 25
i
i
