Installation
4
8. Connect the camera cable as shown in the 3 Connecting the Camera sec-
tion, then feed the cables through the cable hole in the back plate (at-
tached to the mounting surface).
CAUTION
If you run the cables along the mounting surface, you must run the cable through
the side notch on the wall mounting bracket. The camera cable will hang alongside
the wall mounting bracket — see image below for reference:
1. Side Notch
#LX400075; r.41474/41994; en-US
13
