Technical Specifications
8
Image Sensor 1/3", CMOS 4 MP
Video Format NTSC / PAL
Effective Pixels 2592 (H) x 1520 (V)
Resolution Up to 4MP
Range 0°355° Pan; 0°90° Tilt
Pan/Tilt Speed Manual Speed — Max 100°/Sec Pan; Max 60°/Sec Tilt
Preset Speed — Max 100°/Sec Pan; Max 60°/Sec Tilt
Zoom 4x Optical Zoom & 16x Digital Zoom
Scan System Progressive
Synchronization Internal
S / N Ratio ≥50dB
Iris Auto Iris
Min. Illumination 0.2 Lux in Color; 0.02 Lux in Black and White
Lens / Lens Type 2.7mm ~ 11mm, F1.6 ~ F2.8 / Zoom Module
Field of View (Horizontal) 104°33°
Day/Night Auto (ICR) / Color / B/W
Termination RJ45 (10Base-T/100Base-TX) / DC Jack
Video Output IP
Power Requirement PoE (802.3af); 12V DC (Optional)
Power Consumption Max. 850mA
Operating Temperature Range -22°F ~ 140°F / -30°C ~ 60°C
Operating Humidity Range <90%RH
Indoor/Outdoor Both (IP66)
1
Vandal Resistance IK10
Weight (Camera Alone)
Weight (Camera & Wall Mount)
1.20lbs / 0.54kg
2.35lbs / 1.06kg
#LX400075; r. 4.0/58710/58717; en-US 22
1. Not intended for submersion in water. Installation in a sheltered location recommended.
