Mobile
Apps:
Accessing
your
DVR
Using
a
Mobile
Device
18
Manual
Record
Playback
Controls
1.
Back
:
T
ap
to
select
a
different
video
file.
2.
P
ause/Pla
y
.
3.
Stop
.
4.
Slow
.
5.
F
ast
Forwa
rd.
6.
Ne
xt
Frame.
7.
Screenshot.
8.
Mute/Unmute.
9.
Pla
yback
Bar
:
Select
playback
time.
18.3.9
Using
Device
Manager
to
Manage
D
VRs
Y
ou
can
use
the
Device
Manager
to
add,
delete,
or
modify
your
D
VRs.
T
o
delete
a
D
VR:
1.
T
ap
.
#LX400066;
r
.
1.0/26388/26388;
en-US
103
110
112
