Lorex lx4471w User Manual

Using the PC/Mac Client Software
17
4. Drag your mouse cursor over the areas you wish to black out. A red box indicates the
area that is masked (blocked out).
• To remove a privacy area, click on the red box, then click the Delete button.
5. Click Save to apply your settings.
17.11 Configuring Recording Parameters
1. Click the Remote Setting tab, and then click Record>Rec Parameters.
2. Configure the following:
• Channel: Select the channel you wish to configure.
• Record: Select Enable or Disable to start or stop system recording.
• Pre-record: Select whether to enable or disable pre-recording.
3. Click Save to apply your settings.
17.12 Configuring the Recording Schedule
1. Click the Remote Setting tab, and then click Record>Schedule.
#LX400066; r. 1.0/26388/26388; en-US
77

Lorex lx4471w Specifications

General

Brand	Lorex
Model	lx4471w
Category	Security System
Language	English
