Replacing
the
Hard
Drive
21
2.
Gently
lift
the
cover
awa
y
from
the
rear
panel
and
lift
off.
Be
careful
of
sharp
edges.
3.
Attach
the
two
plastic
hard
drive
brackets
to
either
side
of
the
3.5”
hard
drive.
4.
Place
the
hard
drive
in
the
DVR.
Slide
the
hard
drive
gently
forward
to
insert
the
hard
drive
SA
T
A
ports
into
the
D
VR
SA
T
A
connector.
4.1.
D
VR
SA
T
A
connector
4.2.
Hard
drive
SA
T
A
ports
#LX400066;
r
.
1.0/26388/26388;
en-US
124
131
133
