Managing
Pass
words
14
2.
Click
System
>
Users
.
3.
Click
on
a
row
to
select
a
user
account.
4.
Click
the
Edit
button.
5.
Select
the
menus
and
channels
the
user
will
have
access
to:
•
Select
the
menus
the
user
account
will
be
able
to
access.
•
Select
the
channels
the
user
account
will
be
able
to
access
for
each
function.
For
example
,
if
channel
1
is
selected
for
Live,
the
user
account
will
be
able
to
view
live
video
on
channel
1.
