Back panel overview
2
1 2 3 4 5 6 7
1. Power port: Connect power
2. PoE ports: Connect cameras*
3. LAN port: Connect router*
4. VGA port: Connect monitor*
Note:
The 8 channel NVR recorder in this guide is for illustration only. Your recorder may
appear different, with all the same ports in different locations.
*Not included / sold separately.
5. Audio In/Out: Connect microphone / speaker*
6. HDMI port: Connect monitor*
7. USB port: Connect mouse or USB memory stick
