ProtoMat S Functional description
© 2011 LPKF AG HB V0.9/Mrz-11 27
3
Fig. 4: Back view
/1/ Interfaces /2/ Suction pipe with connector for
extraction tube
Fig. 5: Interfaces
/1/ USB port /2/ LPKF ports (4 x SUB-D, 25 pin.)
