ProtoMat S Operation
© 2011 LPKF AG HB V0.9/Mrz-11 85
6
Pos: 30 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_6_Bedien ung/6_10_System_au sschalten @ 0\mod_1254904 321722_2058.doc x @ 3683 @ 233343
6.10 Shutdown the System
Always proceed in the same sequence when shutdown the system:
I Save the current CBF file
II Exit CircuitPro
III Switch off the circuit board plotter
IV Shutdown and switch off the PC
V Switch off the dust extraction
6.10.1 Saving the CBF file
Note
Always save the current production data.
It is possible to save the current production data under the same file name or
under a new file name as well.
■ Saving the CBF file
Note
All existing data will be overwritten!
1. Click File>Save.
♦ The production data was saved by using the current file name.
■ Saving a new CBF file
1. Click File>Save as….
➨ The window “Save as…” is shown:
Fig. 61: Save as…
