ProtoMat S Transport and storage
© 2011 LPKF AG HB V0.9/Mrz-11 39
4
Pos: 15 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_4_Transp ort_Lagerung/4_1_ Transport @ 0\mod_1254 747966635_2058.doc x @ 3631 @ 1232
4 Transport and storage
The following chapter gives some information concerning transport and storage
of the circuit board plotter.
4.1 Transport
ATTENTION
Risk of injury!
The machine is heavy and bulky and cannot be transported or
lifted by one person!
Lift and transport the machine always with two persons.
For transports at large distances the circuit board plotter has to be stored in the
delivered covering box. The covering box has to be placed and fixed on an euro
pallet.
For transports at short distances the circuit board plotter can be take out of the
covering box to be carried by two persons to the working desk.
4.1.1 Transport lock
Fix the mill/drill head with a transport protection band and place a foam mat
under the mill/drill head.
4.2 Storage
Note
The circuit board plotter has to be stored in its covering box in a
cool and dry environment.
At longer down or storage times, transport locks have to be installed and the
circuit board plotters has to be stored in its covering box. Store the circuit board
plotter in a cool and dry location. Use a protective cover to protect it from dust
and humidity.
