ProtoMat S Operation
© 2011 LPKF AG HB V0.9/Mrz-11 65
6
Pos: 26 /ED_Technisc he_Dokumentation/2_Be dienungsanleitun g/Maschine/RP_Fräsb ohrplotter/Pr otoMat_S_Serie/Pr otoMat_S_Serie_II G/Kapitel_6_Bedien ung/6_06_Manuelles_B ohren @ 0\mod_125490426 2916_2058.docx @ 3679 @ 2
6.6 Manual drilling
Note
Every individual tool for the PCB production must be clamped into
the mill/drill head manually, if a circuit board plotter without
automatic tool change function is used.
For the process “manual drilling“ the corresponding drill is inserted into the
collet chuck of the mill/drill head and the drilling position will be reached via
mouse movement. The motor is activated/deactivated by a clicking the start
button as well.
Note
The tools available allow drilling of round holes with a max.
diameter of 3 mm.
ATTENTION
Health hazard!
During machining process of work pieces harmful fine particles
and gases may occur which can be inhaled!
Make sure that the dust extraction is activated during machining
of the work piece. Be sure to use fine particle filters exclusively.
ATTENTION
Risk of injury!
During the machining process the used tools and the collet
chuck heat up, direct contact may cause burnings.
Wear protective gloves and tweezers for manual change of tools
during operation.
ATTENTION
Risk of injury!
The used tools are sharp-edged and cause cut or stab wounds
when used improperly.
Store the tools always in the toolbox and secure the toolbox
against unauthorised utilisation.
