HYDRAULIC SYSTEM SCHEMATIC
Boom
Cylinder
Swing
Cylinders
Left Stabilizer
Cylinder
Dipperstick
Cylinder
Bucket
Cylinder
Right Stabilizer
Cylinder
Tractor or
Pump Kit
- 25 -
