BUCKET, DIPPERSTICK ASSEMBLY
REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
40261812 BT665-23100-01 BUCKET ASS'Y(9) 1
40261813 BT665-23200-01 BUCKET ASS'Y(12) 1
40261814 BT665-23300-01 BUCKET ASS'Y(16) 1
40261815 BT665-23400-01 BUCKET ASS'Y(18) 1
40261816 BT665-23500-01 BUCKET ASS'Y(24) 1
40261817 BT665-23600-01 BUCKET ASS'Y(36) 1
2 40261497 BT400-22100 DIPPERSTICK ASS'Y 1
3 40261820 BT665-25100 LINK ASS'Y 1
4 40261819 BT665-24200-01 LINK-RH 1
5 40261818 BT665-24100-01 LINK-LH 1
6 40231094 BT664-71600-01 PIN,∅30-195.5L 2
7 40261810 BT664-73100 PIN 1
8 40261807 BT664-71800-01 PIN 1
9 40261480 10121-M080C-60 HEX.BOLT,M8-1.25P 60L 4
10 40230896 1021N-M0803 NUT-SELFLOCK,M8-1.25P 4
11 40228707 802G0-T1900 NIPPLE,GREASE,1/8" 4
13 40231037 BH11-0116 SOCKET BRACKET 1
14 40231036 BH11-0115 SOCKET 1
15 40228698 50120-M540K CABLE TIE,540mm BLACK 2
16 40261478 10121-M080B-50 HEX.BOLT 2
17 40228629 10211-M0803 HEX.NUT,M8-1.25P 2
18 40230979 83040-4440D BUSHING,404440 2
19 40230978 83030-3440D BUSHING,303440 2
20 40261495 83032-3640D BUSHING 4
21 40261821 BT665-72100 PIN 2
22 40261483 10121-M100D-65 HEX.BOLT,M10-1.5P 65L 2
23 40228634 1021N-M1004 NUT-SELFLOCK,M10-1.5P 2
1
- 36 -
