SEAT, CONTROL ASSEMBLY(WALVOIL)
REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40294001 BTV02-20200 VALVE ROOM W.A. 1
2 40294002 BTV02-20301 COVER, FRONT 1
3 40294003 BTV02-40102-01 TOP COVER 1
4 40231062 BT651-12240 FOOT PLATE - CENTER 1
5 40231061 BT651-12230-01 FOOT PLATE - RH 1
6 40231060 BT651-12220-01 FOOT PLATE - LH 1
7 40294004 BTV02-70001P GUIDE BAR 1
8 40231053 BN03-0400-01 SWING PIN HANGER 1
9 40231054 BN03-0403 M/C BOSS 1
10 40230892 10191-M1205-30 HEX.BOLT-HT,M12-1.75P 30L 6
11 40228642 10316-M1200 WASHER-SPRING,M12 6
12 40228631 10211-M1205 HEX.NUT,M12-1.75P 6
13 40230889 1012S-M0803-25 BOLT-SEM'S,M8-1.25P 25L 15
14 40228629 10211-M0803 HEX.NUT,M8-1.25P 12
15 40230890 1012S-M0803-40 BOLT-SEM'S,M8-1.25P 40L 4
16 40294005 BTV02-31000 BOOT LEVER ASS'Y 2
17 40294006 BTV02-32000 HAND LEVER 2
18 40231103 BT664-72600 SWING PIN 1
19 40230882 10121-M1004-40 HEX.BOLT,M10-1.5P 40L 1
20 40231081 BT664-41110-01 SUPPORT SEAT 1
21 40256413 BTA02-20200 PLATE, SEAT 1
22 40231138 V-2400 SEAT 1
23 40231083 BT664-41130-01 LINK ASS'Y 1
24 40231084 BT664-41150 PIN, ∅12 1
25 40255401 10121-M1205-A0 HEX.BOLT,M12-1.75P 100L 1
26 40230887 10121-M120E-B0 HEX.BOLT,M12-1.75P 110L 1
27 40228642 10316-M1200 WASHER-SPRING,M12 6
28 40228635 1021N-M1205 NUT-SELFLOCK,M12-1.75P 2
29 40228615 10191-M1205-35 HEX.BOLT-HT,M12-1.75P 35L 4
30 40230900 1200-0364 HEX.BOLT-HT,5/16-18 3/4" 4
31 40228640 10316-M0800 WASHER-SPRING,M8 4
32 40228646 10321-M0800 WASHER-PLAIN,M8 4
33 40228655 14011-03000 R-PIN,∅
3 1
- 44 -
