HOSE FITTING ASSEMBLY
REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40228612 1012S-M0803-35 BOLT-SEM'S,M8-1.25P 35L 4
2 40261476 227102 BUCKET CYLINDER ASSEMBLY 1
3 40261475 227101 DIPPERSTICK CYLINDER ASSEMBLY 1
4 40261477 227103 BOOM CYLINDER ASSEMBLY 1
5 40230918 225806 SWING CYLINDER ASSEMBLY 2
6 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 1
7 40230913 224305 STABILIZER CYLINDER ASSEMBLY-RH 1
8 40230948 6003-0204
ADAPTER LONG,1/2-20UNF×3/4-16UNF,O-RING
4
9 40230949 6003-0205
ORIFICE LONG,1/2-20UNF×3/4-16UNF,O-RING
2
10 40230947 6003-0203
ADAPTER SHORT,1/2-20UNF×3/4-16UNF,O-RING
4
11 40230950 6003-0206
ORIFICE SHORT,1/2-20UNF×3/4-16UNF,O-RING
2
12 40230951 6003-0302
ADAPTER ELBOW,3/4-16UNF×7/8-14UNF,O-RING 90˚
2
13 40230952 6003-0408 NIPPLE,PT1/2×3/4-16UNF 2
14 40230971 8044K-01100 DUST-CAP,1/2" BLACK FEMALE 2
15 40230967 80410-T1130 QUICK COUPLER,PT1/2 MALE 2
16 40230953 6004-0205 NIPPLE,PF1/4,O-RING×1/2-20UNF 16
17 40230962 802N1-F67F7-50 NIPPLE,9/16-18UNF×1/2-20UNF 2
18 40230943 5004-0034 O-RING, AS568 #908,AS568 #908 12
19 40230700 81300-0P011 O-RING,P11 16
20 40230944 5004-0078 O-RING, AS568 #910,AS568 #910 2
21 40231109 BT664-83100
NIPPLE KIT,1/2-20UNF×1/2-20UNF,NUT
2
22 40261822 BT665-82140 PIPE ASS'Y 1
23 40231108 BT664-82150 PIPE ASS'Y 1
24 40230963 802N1-P26F7-52 ADAPTER,PF1/4×9/16-18UNF 2
25 40231038 BH30-0100 HOSE ASS'Y,1/4×4×4×550L 2
26 40231039 BH30-0200 HOSE ASS'Y,1/4×904×4×950L 2
27 40231040 BH30-0300 HOSE ASS'Y,1/4×904×4×1300L 4
28 40261823 BT665-83120 HOSE ASS'Y 2
29 40261824 BT665-83130 HOSE ASS'Y 2
30 40231112 BT664-83140 HOSE ASS'Y,1/4×4×4G/W×900L 2
31 40231113 BT664-83150 HOSE ASS'Y,1/4×904×4×1850L 2
32 40261811 BT664-83160-01 HOSE ASS'Y 2
33 40228698 50120-M540K CABLE TIE,540mm BLACK 3
34 40231115 COM02-11101 FIX, PIPE 2
35 40230958 802L0-T63FA-32
NIPPLE,PT1/2×7/8-14UNF,O-RING 90˚
1
36 40230955 801K1-13000 CHECK VALVE,PT1/2-0.5K 1
37 40230966 802N3-T63FA-30 NIPPLE,PT1/2×7/8-14UNF,HOSE 1
- 46 -
