HOSE FITTING ASSEMBLY(WALVOIL)
REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40294009 8WKEXP2124 VALVE,WALVOIL SD6/6 1
2 40261476 227102 BUCKET CYLINDER ASSEMBLY 1
3 40261475 227101 DIPPERSTICK CYLINDER ASSEMBLY 1
4 40261477 227103 BOOM CYLINDER ASSEMBLY 1
5 40230918 225806 SWING CYLINDER ASSEMBLY 2
6 40230910 224304 STABILIZER CYLINDER ASSEMBLY-LH 1
7 40230913 224305 STABILIZER CYLINDER ASSEMBLY-RH 1
8 40230948 6003-0204
ADAPTER LONG,1/2-20UNF×3/4-16UNF,O-RING
4
9 40230949 6003-0205
ORIFICE LONG,1/2-20UNF×3/4-16UNF,O-RING
2
10 40230947 6003-0203
ADAPTER SHORT,1/2-20UNF×3/4-16UNF,O-RING
4
11 40230950 6003-0206
ORIFICE SHORT,1/2-20UNF×3/4-16UNF,O-RING
2
12 40294010 802L3-FA3FA-32
ADAPTER ELBOW,7/8-14UNF,HOSE×7/8-14UNF,O-RING 90°
2
13 40230966 802N3-T63FA-30 NIPPLE,PT1/2×7/8-14UNF,HOSE 2
14 40230971 8044K-01100 DUST-CAP,1/2" BLACK FEMALE 2
15 40230967 80410-T1130 QUICK COUPLER,PT1/2 MALE 2
16 40230953 6004-0205 NIPPLE,PF1/4,O-RING×1/2-20UNF 14
17 40230962 802N1-F67F7-50 NIPPLE,9/16-18UNF×1/2-20UNF 2
18 40230943 5004-0034 O-RING, AS568 #908,AS568 #908 12
19 40230701 81301-BP011 O-RING,1BP11 16
20 40230944 5004-0078 O-RING, AS568 #910,AS568 #910 2
21 40231109 BT664-83100
NIPPLE KIT,1/2-20UNF×1/2-20UNF,NUT
2
22 40294008 BT500-02000 PIPE ASS'Y 1
23 40294077 BT500-03000 PIPE ASS'Y 1
24 40230963 802N1-P26F7-52 ADAPTER,PF1/4×9/16-18UNF 2
25 40231038 BH30-0100 HOSE ASS'Y,1/4×4×4×550L 2
26 40231039 BH30-0200 HOSE ASS'Y,1/4×904×4×950L 2
27 40231040 BH30-0300 HOSE ASS'Y,1/4×904×4×1300L 4
28 40294073 80610-05015
HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 2700L(1/4)
2
29 40294074 80610-05019
HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 2900L(1/4)
2
30 40231112 BT664-83140 HOSE ASS'Y,1/4×4×4G/W×900L 2
31 40294011 80610-05030
HOSE ASS'Y,904(1/2-20UNF)-4(1/2-20UNF) 1890L(1/4)
2
32 40294076 80630-01005
HOSE ASS'Y,4(7/8-14UNF)-4(7/8-14UNF) 1900L(1/2)
2
33 40228698 50120-M540K CABLE TIE,540mm BLACK 3
34 40231115 COM02-11101 FIX, PIPE 2
35 40230889 1012S-M0803-25 BOLT-SEM'S,M8-1.25P 25L 4
- 48 -
