CONTROL VALVE ASSEMBLY-HANIL AV 80/6
REF.NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
0 40230982 BC04-0000-P CONTROL VALVE ASS'Y 1
1 40230983 BC04-0100 BLOCK-BA TYPE(INLET) 1
2 40230984 BC04-0200 BLOCK-HB TYPE(BOOM) 1
3 40230985 BC04-0300 BLOCK-HA TYPE 2
4 40230986 BC04-0400 BLOCK-EA TYPE 3
5 40230987 BC04-0500 BLOCK-GB TYPE (OUTLET) 1
6 40230988 BC04-0600 O-RING 7
7 40230989 BC04-0700 PLUG ASS'Y 1
8 40230990 BC04-0800 POPPET-CHECK 6
9 40230991 BC04-0900 SPRING-CHECK 6
10 40230992 BC04-1000 PLUG-CHECK ASS'Y 6
11 40230993 BC04-1100 M.R.V.ASS'Y 1
12 40230994 BC04-1200 O.R.V.ASS'Y 4
13 40230995 BC04-1300 A.C.V.ASS'Y 2
14 40230996 BC04-1400 SPOOL ASS'Y-FLOAT 1
15 40230997 BC04-1500 SPOOL ASS'Y-STD 3
16 40230998 BC04-1600 SPOOL ASS'Y-STABILIZER 2
17 40230999 BC04-1700 RETURN CAP 6
18 40231000 BC04-1800 WRENCH BOLT 18
19 40231001 BC04-1900 HOUSING-DETENT 1
20 40231002 BC04-2000 SOCKET-DETENT 1
21 40231003 BC04-2100 BALL-DETENT 4
22 40231004 BC04-2200 SLEEVE-DETENT 1
23 40231005 BC04-2300 SPRING-RETURN 1
24 40231006 BC04-2400 WRENCH BOLT 2
25 40231007 BC04-2500 O-RING 1
26 40231008 BC04-2600 SEAL KIT ASS'Y-FLOAT 1
27 40231009 BC04-2700 O-RING 5
28 40231010 BC04-2800 DUST WIPER 5
29 40231011 BC04-2900 SEAL PLATE 3
30 40231012 BC04-3000 BRACKET-STABILIZER 2
31 40231013 BC04-3100 WRENCH BOLT 6
32 40231014 BC04-3200 BRACKET-JOINT 2
33 40231015 BC04-3300 SUPPORT-JOINT 2
34 40231016 BC04-3400 BLOCK-JOINT 2
35 40231017 BC04-3500 SUPPORT-BALL 6
36 40231018 BC04-3600 NYLON NUT 6
37 40231019 BC04-3700 LEVER-STABILIZER 2
38 40231020 BC04-3800 PIN 4
39 40231021 BC04-3900 WASHER-PIN 4
40 40231022 BC04-4000 SNAP PIN 4
41 40231023 BC04-4100 SPRING PIN 4
42 40231024 BC04-4200 NUT 8
43 40231025 BC04-4300 TIE BOLT 4
44 40231026 BC04-4400 BOOT , CONTROL 2
45 40231027 BC04-4500 HAND LEVER 2
46 40231028 BC04-4600 BOOT , CONTROL 2
47 40231029 BC04-4700 HAND LEVER 2
48 40230981 BC01-2400 PLASTIC BALL 2
49 40231030 BC04-4900 LEVER STICK 2
50 40228630 10211-M1004 HEX.NUT,M10-1.5P 4
51 40231031 BC04-5100 PLASTIC BALL 2
52 40231032 BC04-5200 LEVER STICK 2
