DECK ASSEMBLY
REF.NO LS PART.NO DESCRIPTION QTY I.C
SERIAL OR DATE
1~37
40378740 Deck Ass'y 1
1 40383757 Deck WA 1
40431556 Deck WA 1 2020.02.28.~
40462207 Deck WA 1 MM60AE0025~(2022.06.20~)
2 40372129 Gearbox Bracket WA - LH 1
3 40372130 Gearbox Bracket WA - RH 1
4 40365481 Center Spindle Ass'y 1
5 40372131 Side Spindle Ass'y 2
6 40365497 Tension Ass'y 1
7 40365502 Wheel Ass'y 4
8 40365470 Wheel Lock Pin 4
9 40365471 Discharge PIN 1
10 40365472 Support Wheel Shaft 1
11 40365460 Tensioner Spring 1
12 40365459 Discharge Spring 1
13 40365458 Ring Lock Pin 4
14 40378313 Belt Cover - LH 1
15 40378314 Belt Cover - RH 1
16 40378724 Discharge Deflector 1
17 40365476 Bottom Cover 1
18 40365477 Washer, ∅24x∅10.2x3.2T 4
19 40255447 Support Wheel 1
20 40365468 Belt 1
40394368 Belt 1 2018.11.06.~
21 40365449 Hex. Bolt-HT, M12-P1.25-35L 8
22 40365450 Hex. Bolt-HT, M12-P1.25-40L 4
23 40365447 Hex. Bolt-HT, M10-P1.5-25L 4
24 40365448 Hex. Bolt-HT, M10-P1.5-70L 2
25 40365446 Hex. Bolt-HT, M8-P1.25-20L 4
26 40194098 Knob, M8-1.25-20L 4
27 40228642 Washer-Spring, M12 13
28 40228641 Washer-Spring, M10 4
29 40228640 Washer-Spring, M8 4
30 40255416 Washer-Plain, M20 1
31 40228648 Washer-Plain, M12 3
32 40365453 Hex. Nut, M12-P1.25 12
33 40230897 Hex. Nut, M12-P1.75 1
34 40305381 Hex. Nut, M10-P1.5 2
35 40228629 Hex. Nut, M8-P1.25 4
36 40230896 Nut-Self Locking, M8-P1.25 2
37 40255422 Split PIN, ∅3-40L 2
