CENTER PULLEY ASSEMBLY
REF.NO LS PART.NO DESCRIPTION QTY I.C
SERIAL OR DATE
1 40365490 Gear Box Ass'y 1
2 40365482 Center Pulley 1
3 40365483 Center Housing 1
4 40365484 End Holder 1
5 40365485 Dust Cover 1
6 40365486 Conical Washer 1
7 40365487 Hexagonal Washer 1
8 40365488 Lock Washer 1
9 40365489 Blade 1
10 40365450 Hex. Bolt-HT, M12-P1.25-40L 1
11 40228642 Washer-Spring, M12 1
12 40365465 Oil Seal, ∅35x∅52x7L 1
13 40365463 Ball Bearing, 6205 1
14 40365456 Snap Ring, R52 1
15 40365461 Key, 7x7x28L-2R 1
16 40365462 Nipple-Grease, PT1/8", 90° 1
17 40365466 Oil Seal, ∅40x∅55x8L 1
- 33 -
