SIDE PULLEY ASSEMBLY
REF.NO LS PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40365492 Side Housing 1
2 40365493 Bearing Spacer 1
3 40365494 Side Spindle Shaft 1
4 40372132 Side Pulley 1
5 40365496 Side Pulley Holder 1
6 40365485 Dust Cover 1
7 40365486 Conical Washer 1
8 40365487 Hexagonal Washer 1
9 40365488 Lock Washer 1
10 40365489 blade 1
11 40365450 Hex.Bolt-HT, M12-P1.25-40L 1
12 40228642 Washer-Spring, M12 1
13 40365463 Ball Bearing, 6205 2
14 40365465 Oil Seal, ∅35x∅52x7L 2
15 40365456 Snap Ring, R52 1
16 40228707 Nipple-Grease, PT1/8" 1
17 40365454 Hex Nut, M18-P1.5 1
18 40230613 Washer-Spring, M18 1
19 40228612 Sem's Bolt, M8-P1.25-35L 4
20 40365452 Hex Nut, M8-P1.25 4
- 35 -
