MID PTO 1 speed gear (15T)

PTO / Engine speed 2500 / 2647 rpm

Rotation direction Counter clockwise (When looking at PTO shaft end)

Shaft dimension

(Unit : inch)

③ Specification and Dimension of Middle PTO shaft

- Spline Teeth: 15T (Where fitted)

Module : DP 16/32

Number of Teeth : 15T

(0.84 in.)

(0.98 in.)

(1.89 in)

(0.94 in)

(1.54 in)
