3. Instruments and Controls
3-1. Instrument panel and Front controls
Important to owner
, read carefully
Brake pedals
Mult
i fun
ctional
light switch
HST reverse pedal
Instrument
pane
l
Key switch
Throttle
lev
er
Cruse control lever
Parking brake lever
HST forward pedal
HST type
Steering tilt pedal
(See chapter 2-1-(4))
56
58
Table of Contents
