LS tractor MT2 Series - Turn Signal Lights, Lights and Horn

5 -19
(4) Turn signal lights, Lights and Horn
 Check the operational status of the headlights, turn signal lights, horn and other illumination lights.
▶ Use the bulb of rated capacity. If using an improper bulb arbitrary, it may cause a
failure of the electric system.
Notice
Illuminating Lights Light bulb specification
Headlights (Low beam / High beam) 12V 35W / N/A
Turn signal lights (front / rear) 12V 21W
Side lights (front / rear) N/A
Stop lights / Taillights (rear) 12V 21W / 5W
Work light(s) (optional) 12V 27W (Roll-bar)
Instrument panel lights and indicators LED
Horn switch
(If fitted)
Turn signal
light switch
Light switch
 If the light is OFF suddenly when operating the switch, check the problems as followings.
1. Check the related fuse in the fuse box.
2. Check the light bulb. If necessary, replace it with a new one. See below table and refer to the
chapter 5-12-(5), 5-12-(6) in this manual.
