2. Instruction for Safe Operation

(1) The name of each part

- HST type

Tires

Hood

(Bonnet)

Fuel tank

Fender

Instrument panel

Steering wheel

Driver’s seat

Roll-bar

(ROPS)

Headlights

Sub step

Front weight ballast(optional)
