5 -49
(2) Fuse & Main fuse
< Fuse box for the chassis >
< Cabin fuse box (Cabin type) >
Cabin fuse
box cover
Chassis fuse box
① Fuse check and replacement
How to change the fuse.
1. Remove the fuse box cover.
2. Check each fuse and remove the damaged one.
3. Replace it with a new one of the same capacity
as the damaged fuse.
Chassis fuse box is installed under the front
console and cabin fuse box is on the left cabin
pillar.
The capacity and function of each fuse is
described on the fuse box cover.
▶If the same function fuse is damaged repeatedly, contact your authorized local
dealer for check instead of using a substitute such as wire or aluminum foil.
▶If using the substitute instead of the rated capacity fuse, it may cause a fire which
results in damage of the tractor or personal injury.
Caution
