2 -1

2. Instruction for Safe Operation

(1) The name of each part

① Roll-Bar type

Instrument panel

Steering wheel

Driver’s

Seat

Sub step

Head lights

Bonnet (Hood)

Front ballast weight

(optional)

Front axle

Fender

Fuel tank

ROPS

(Roll bar)
