5 -12
For safety, the hood must be closed and
correctly latched before operating the tractor.
The hood is hinged at the rear and a gas
cylinder is attached to provide easy access to
the engine for check and maintenance.
To open the hood, push the hood opening knob
and lift the hood up.
To close the hood, pull the hood and push it
down to the locking position slightly.
Hood opening knob
▶ After the engine has stopped completely, you have to open the hood for checking.
▶ If you open the hood while the engine is running, it can cause serious damage by
intended or unintended access to the rotating shaft, pulley, V-belt, cooling fan of the
engine or engine application parts. PLEASE BE CAREFUL.
Caution
(7) Access for maintenance
① Opening Hood
