5 -51
① Fuse check and replacement
How to change the fuse
1. Remove the fuse box cover.
2. Check each fuse and remove the damaged one.
3. Replace it with a new one of the same capacity
as the damaged one.
Chassis fuse box is installed under the front
console cover.
The capacity and function of each fuse is
described on the fuse box cover.
(2) Fuse & Main fuse
Chassis fuse box
< Chassis fuse box >
▶If the same function fuse is damaged repeatedly, contact your authorized local
dealer for check instead of using a substitute such as wire or aluminum foil.
▶If using the substitute instead of the rated capacity fuse, it may cause a fire which
results in damage of the tractor or personal injury.
Caution
