LS tractor MT345E

To Next Page

To Previous Page

3 -2

HST type

Light switch

Turn signal

light switch

Hazard warning

light indicator

Grille work

light switch

Cruse control

switch

DPF switch

Key switch

Brake pedals

HST reverse pedal

Instrument panel

Throttle lever

PTO switch

PTO mode switch

(optional)

Parking brake lever HST forward pedal

Important to owner, read carefully
