LS SV008iS5-2 - Page 165

Chapter 7 - Options
159
AOC
R
S
T
G
U
V
W
FX
RX
BX
RST
JOG
P1
P2
P3
CM
VR
V1
5G
IM
Motor
3
phase
AC
input
BOC
A+
A-
B+
B-
FBA
FBB
GND
E
Encoder
GND
+5V
+5V
VCC
VCC
Sub-B
MCNFC
FWD Run/Stop
REV Run/Stop
Emergency stop
Fault reset
JOG
I
Potentiometer
1 kohm, 1/2W
24 V
FM
5G
30A
30C
30B
AXA
AXC
Encoder
signal
(LD) input
Encoder
signal
output
Encoder
signal
ground
Note) 1. : Main circuit, : Control circuit.
2. External speed signal: V1, I, V1+I (Refer to Parameter list)
Shield
+5 V power
output to
Encoder
1. Sub-B board with
Line Drive type encoder
I/O-12~14 :
Factory setting:
Multi-speed input
(Speed-L, M, H)
Common Terminal
Multi-function
input 1
Multi-function
input 2
Multi-function
input 3
Power supply for
speed signal
+12V 10mA
Speed signal input
0~10V(1 kohm)
Speed signal input
4~20mA (250ohm)
(Common for
VR, V1, I )
Maximum
current thru
PC: 5mA
