LS SV008iS5-2 User Manual

Chapter 5 - Parameter List
70
5.5 External Group [EXT]
EXT group appears only when the corresponding Sub-Board is installed.
Keypad Display Setting Range
Code Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
EXT-00
Jump to Desired Code #
Jump code Not displayed
0 to 99 Not available
1 1 Yes
136
None 0
SUB-A 1
SUB-B 2
SUB-C 3
SUB-D 4
SUB-E 5
SUB-F 6
SUB-G 7
EXT-01
Sub Board Type Display
Sub B/D 01
SUB-H 8
- None
Automa
tically
set
136
Speed-L 0
Speed-M 1
Speed-H 2
XCEL-L 3
XCEL-M 4
XCEL-H 5
Dc-brake 6
2nd Func 7
Exchange 8
- Reserved - 9
Up 10
Down 11
3-Wire 12
Ext Trip-A 13
Ext Trip-B 14
iTerm Clear 15
Open-loop 16
Main-drive 17
Analog hold 18
XCEL stop 19
P Gain2 20
SEQ-L 21
SEQ-M 22
SEQ-H 23
Manual 24
Go step 25
Hold step 26
Trv Off.Lo 27
Trv Off.Hi 28
Interlock1 29
Interlock2 30
Interlock3 31
EXT-02
Multi-Function Input
Terminal ‘P4’ Define
P4 define 02
Interlock4 32
- XCEL-L
Yes
136
