LS SV008iS5-2 User Manual

Chapter 5 - Parameter List
60
5.3 Function 2 Group [FU2]
Keypad Display Setting Range
Code Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
FU2-00
Jump to desired code # Jump code Not displayed
1 to 99 Not available
1 1 Yes
99
FU2-01
Previous Fault History 1
Last trip-1 01
FU2-02
Previous Fault History 2
Last trip-2 02
FU2-03
Previous Fault History 3
Last trip-3 03
FU2-04
Previous Fault History 4
Last trip-4 04
FU2-05
Previous Fault History 5
Last trip-5 05
By pressing [PROG] and [▲] key,
the frequency, current, and
operational status at the time of fault
can be seen.
- None -
No 0
FU2-06
Erase Fault History Erase trips 06
Yes 1
- No Yes
99
FU2-07
Dwell Frequency Dwell freq 07 FU1-22 to FU1-20 0.01
5.00 [Hz]
No
FU2-08
Dwell Time Dwell time 08 0 to 10 [sec] 0.1
0.0 [sec]
No
100
No 0
FU2-10
Frequency Jump
Selection
Jump freq 10
Yes 1
- No No
FU2-11
18
Jump Frequency 1 Low Jump lo 1 11 0 to FU2-12 0.01
10.00 [Hz]
Yes
FU2-12
Jump Frequency 1 High
Jump Hi 1 12 FU2-11 to FU1-20 0.01
15.00 [Hz]
Yes
FU2-13
Jump Frequency 2 Low Jump lo 2 13 0 to FU2-14 0.01
20.00 [Hz]
Yes
FU2-14
Jump Frequency 2 High
Jump Hi 2 14 FU2-13 to FU1-20 0.01
25.00 [Hz]
Yes
FU2-15
Jump Frequency 3 Low Jump lo 3 15 0 to FU2-16 0.01
30.00 [Hz]
Yes
FU2-16
Jump Frequency 3 High
Jump Hi 3 16 FU2-15 to FU1-20 0.01
35.00 [Hz]
Yes
100
FU2-17
Start Curve for S-Curve
Accel/Dedel Pattern
Start Curve 17 0 to 100 [%] 1 40% No 101
FU2-18
End Curve for S-Curve
Accel/Dedel Pattern
End Curve 18 0 to 100 [%] 1 40% No 101
FU2-19
Input/Output Phase Loss
Protection
Trip select 19
00 to 11
(Bit Set)
- 00 Yes
101
No 0
FU2-20
Power ON Start Selection
Power-on run 20
Yes 1
- No Yes
101
No 0
FU2-21
Restart after Fault Reset
RST restart 21
Yes 1
- No Yes
102
FU2-22
Speed Search Selection
Speed Search
22
0000 to 1111
(Bit Set)
- 0000 No
FU2-23
Current Limit Level
During Speed Search
SS Sup-Curr 23 80 to 200 [%] 1 150 [%]
Yes
FU2-24
P Gain
During Speed Search
SS P-gain 24 0 to 9999 1 100 Yes
FU2-25
I Gain
During speed search
SS I-gain 25 0 to 9999 1 200 Yes
102
FU2-26
Number of Auto Restart
Attempt
Retry number
26 0 to 10 1 0 Yes
103
FU2-27
Delay Time
Before Auto Restart
Retry Delay 27 0 to 60 [sec] 0.1
1.0 [sec]
Yes
103
FU2-28
Speed Search Hold Time
SS blk time 28 0 to 60 [sec] 0.1
1.0 [sec]
No 104
FU2-30
Rated Motor Selection Motor select 30 0.75kW 0 -
19
No 104
18
Code FU2-11 through FU2-16 appears only when FU2-10 is set to ‘Yes’.
