192
APPENDIX C- PERIPHERAL DEVICES
Wire, mm
2
(AWG) Inverter
Models
Motor
[HP]
MCCB, ELB
Magnetic
Contactor
R, S, T
AC Input
Fuse
AC Reactor DC Reactor
SV008iS5-2 1
TD125U/EBS33b
GMC-9
2 (14) 2 (14) 3.5 (12)
10 A 2.13 mH, 5.7 A 7.00 mH, 5.4 A
SV015iS5-2 2
TD125U/EBS33b
GMC-12
2 (14) 2 (14) 3.5 (12)
15 A 1.20 mH, 10 A 4.05 mH, 9.2 A
SV022iS5-2 3
TD125U/EBS33b
GMC-18
2 (14) 2 (14) 3.5 (12)
25 A 0.88 mH, 14 A 2.92 mH, 13 A
SV037iS5-2 5
TD125U/EBS33b
GMC-32
3.5 (12)
40 A 0.56 mH, 20 A 1.98 mH, 19 A
SV055iS5-2 7.5
TD125U/EBS53b
GMC-40
5.5 (10)
40 A 0.39 mH, 30 A 1.37 mH, 29 A
SV075iS5-2 10
TD125U/EBS63b
GMC-50
8 (8) 8 (8) 5.5 (10)
50 A 0.28 mH, 40 A 1.05 mH, 38 A
SV110iS5-2 15
TD125U/EBS103b
GMC-65
14 (6) 14 (6) 14 (6) 70 A 0.20 mH, 59 A 0.74 mH, 56 A
SV150iS5-2 20
TD125U/EBS203b
GMC-100
22 (4) 22 (4) 14 (6) 100 A 0.15 mH, 75 A 0.57 mH, 71 A
SV185iS5-2 25
TS250U/EBS203b
GMC-125
30 (3) 30 (3) 22 (4) 100 A 0.12 mH, 96 A 0.49 mH, 91 A
SV220iS5-2 30
TS250U/EBS203b
GMC-150
38(2) 30 (3) 22 (4) 125 A 0.10 mH, 112 A 0.42 mH, 107 A
SV300iS5-2 40
TS250U/EBS203b
GMC-180
60(2/0)
22 (4) 190 A 0.07 mH, 160 A 0.34 mH, 152 A
SV370iS5-2 50
TS400U/EBS403b
GMC-220
60(2/0)
22 (4) 220 A 0.06 mH, 191 A 0.29 mH, 181 A
SV450iS5-2 60
TS400U/EBS403b
GMC-300
100(4/0)
38 (2) 270 A 0.05 mH, 223 A 0.29 mH, 233 A
SV550iS5-2 75
TS800U/EBS603b
GMC-400
100(4/0)
38 (2) 330 A 0.04 mH, 285 A 0.25 mH, 270 A
SV008iS5-4 1
TD125U/EBS33b
GMC-9
2 (14) 2 (14) 2 (14) 6 A 8.63 mH, 2.8 A 28.62 mH, 2.7 A
SV015iS5-4 2
TD125U/EBS33b
GMC-9
2 (14) 2 (14) 2 (14) 10 A 4.81 mH, 4.8 A 16.14 mH, 4.6 A
SV022iS5-4 3
TD125U/EBS33b
GMC-12
2 (14) 2 (14) 2 (14) 10 A 3.23 mH, 7.5 A 11.66 mH, 7.1 A
SV037iS5-4 5
TD125U/EBS33b
GMC-18
2 (14) 2 (14) 2 (14) 20 A 2.34 mH, 10 A 7.83 mH, 10 A
SV055iS5-4 7.5
TD125U/EBS33b
GMC-22
3.5 (12)
20 A 1.22 mH, 15 A 5.34 mH, 14 A
SV075iS5-4 10
TD125U/EBS33b
GMC-32
3.5 (12)
30 A 1.14 mH, 20 A 4.04 mH, 19 A
SV110iS5-4 15
TD125U/EBS53b
GMC-40
5.5 (10)
8 (8) 35 A 0.81 mH, 30 A 2.76 mH, 29 A
SV150iS5-4 20
TD125U/EBS63b
GMC-50
14 (6) 8 (8) 8 (8) 45 A 0.61 mH, 38 A 2.18 mH, 36 A
SV185iS5-4 25
TD125U/EBS103b
GMC-65
14 (6) 8 (8) 14 (6) 60 A 0.45 mH, 50 A 1.79 mH, 48 A
SV220iS5-4 30
TD125U/EBS103b
GMC-65
22 (4) 14 (6) 14 (6) 70 A 0.39 mH, 58 A 1.54 mH, 55 A
SV300iS5-4 40
TD125U/EBS203b
GMC-100
22 (4) 22 (4) 14 (6) 90 A 0.287mH, 80A 1.191mH, 76A
SV370iS5-4 50
TS250U/EBS203b
GMC-125
22 (4) 22 (4) 14 (6) 110 A 0.232mH, 98A 0.975mH, 93A
SV450iS5-4 60
TS250U/EBS203b
GMC-150
38(2) 38(2) 22 (4) 140 A 0.195mH, 118A 0.886mH, 112A
SV550iS5-4 75
TS250U/EBS203b
GMC-180
38(2) 38(2) 22 (4) 170 A 0.157mH, 142A 0.753mH, 135A
SV750iS5-4 100
TS400U/EBS403b
GMC-220
60(2/0)
22 (4) 230 A 0.122mH, 196A 0.436mH, 187A
Note
1. The capacity of the MCCB should be 1.5 to 2 times the rated output current of the drive.
2. Use an MCCB keep the drive from faulting out instead of using overheat protection (150% for
one minute at the rated output current.)
