Chapter 5 - Parameter List

Keypad Display Setting Range

Code Description

LCD 7-Segment

Units

Factory

Default

Adj.

During

Run

Page

Analog hold 18

XCEL stop 19

P Gain2 20

SEQ-L 21

SEQ-M 22

SEQ-H 23

Manual 24

Go step 25

Hold step 26

Trv Off.Lo 27

Trv Off.Hi 28

Interlock1 29

Interlock2 30

Interlock3 31

Interlock4 32

Speed-X 33

Reset 34

BX 35

JOG 36

FX 37

RX 38

Ana Change 39

Pre excite 40

Spd/Trq 41

ASR P/PI 42

I/O-13

Multi-function Input

Terminal ‘P2’ Define

P2 define 13 - Speed-M

Yes

I/O-14

Multi-function Input

Terminal ‘P3’ Define

P3 define 14

Same as Above

- Speed-H

Yes

120

I/O-15 Terminal Input Status In status 15 000000000 to 111111111 - - -

I/O-16 Terminal Output Status Out status 16 0000 to 1111 - - -

126

I/O-17

Filtering Time Constant

for Multi-Function Input

Terminals

Ti Filt Num 17 2 to 50 1 15 Yes

126

I/O-20 Jog Frequency Setting Jog freq 20 10.00 [Hz]

Yes

126

I/O-21 Step Frequency 4 Step freq-4 21 40.00 [Hz]

Yes

I/O-22 Step Frequency 5 Step freq-5 22 50.00 [Hz]

Yes

I/O-23 Step Frequency 6 Step freq-6 23 40.00 [Hz]

Yes

I/O-24 Step Frequency 7 Step freq-7 24

0 to FU1-20 0.01

30.00 [Hz]

Yes

126

I/O-25

Acceleration Time 1

for Step Frequency

Acc time-1 25 0 to 6000 [sec] 0.1

20.0 [sec]

Yes

I/O-26

Deceleration Time 1

for Step Frequency

Dec time-1 26 0 to 6000 [sec] 0.1

20.0 [sec]

Yes

I/O-27 Acceleration Time 2 Acc time-2 27 0 to 6000 [sec] 0.1

30.0 [sec]

Yes

I/O-28 Deceleration Time 2 Dec time-2 28 0 to 6000 [sec] 0.1

30.0 [sec]

Yes

I/O-29 Acceleration Time 3 Acc time-3 29 0 to 6000 [sec] 0.1

40.0 [sec]

Yes

127
