Cables
www.lsi.com/channel/products 7
Cables
Internal SFF-8087 Cable with Sideband Support
Use with the internal connectors of the 9750 family of 3ware RAID
controllers.
Figure 7. Typical Internal SFF-8087 Cable
External SFF-8088 Cable
Use with the external connectors of the 9750 family of 3ware RAID
controllers.
Figure 8. Typical External SFF-8088 Cable
Important: You should only use LSI 3ware certified cables
with your LSI 3ware RAID controller. Using an incorrect cable
can result in drives that are not detected. The appropriate
cables are included with your controller. If you must replace a
cable, see the list of available cables and associated part
numbers at http://www.lsi.com/channel/products/
raid_controllers/accessories/cables.
