LSI 3ware 9750 Installation Guide

Chapter 1. Getting Started
2 LSI 3ware 9750 SATA+SAS RAID Controller Card Installation Guide
Contents of this Package
If you purchased a full retail kit with cables, the following items are
included:
 One of the 3ware 9750 RAID controller card models in Table 1.
 This document, LSI 3ware 9750 SATA+SAS RAID Controller
Card Installation Guide.
 3ware CD-ROM with driver, software, and additional
documentation.
 Appropriate cables for your 9750 RAID controller card see
Table 2, also see “Cables” on page 7.
Table 1: 9750 Controller Card Family
Model Ports Description
9750-4i 4 One internal 4x wide port.
9750-8i 8 Two internal 4x wide ports.
9750-4i4e 8 One internal 4x wide port, one external 4x wide
port.
9750-8e 8 Two external 4x wide ports.
9750-16i4e 20 Four internal 4x wide ports, one external 4x wide
port.
9750-24i4e 28 Six internal 4x wide ports, one external 4x wide
port.
Table 2: Cable and Connectors for the 9750 Family
Model
Internal
Connectors
External
Connectors
Cable
9750-4i 1 x SFF8087 – One internal 4 lane
SATA+SAS cable with
sideband support.

LSI 3ware 9750 Specifications

General

Brand	LSI
Model	3ware 9750
Category	Controller
Language	English
