LSI 3ware 9750 Installation Guide

Contents of this Package
www.lsi.com/channel/products 3
9750-8i 2 x SFF8087 – Two internal 4 lane
SATA+SAS cables with
sideband support.
9750-4i4e 1 x SFF8087 1 x SFF8088 One internal 4 lane
SATA+SAS cable with
sideband support. One
external 4 lane
SATA+SAS cable.
9750-8e – 2 x SFF8088 Two external 4x lane
SATA+SAS cables.
9750-16i4e 4 x SFF8087 1 x SFF8088 Four internal 4x lane
SATA+SAS cables with
sideband support. One
external 4x lane
SATA+SAS cable.
9750-24i4e 6 x SFF8087 1 x SFF8088 Six internal 4x lane
SATA+SAS cable with
sideband support, one
external 4x lane
SATA+SAS cable.
Table 2: Cable and Connectors for the 9750 Family (continued)
Model
Internal
Connectors
External
Connectors
Cable

LSI 3ware 9750 Specifications

General

Brand	LSI
Model	3ware 9750
Category	Controller
Language	English
