LSI 3ware 9750 Installation Guide

Environmental Specification
www.lsi.com/channel/products 25
Environmental Specification
The 9750 SATA+SAS RAID Controller card environmental
requirements are listed in
Table 5.
Table 5: Controller Environmental Specification
Specification Operating Non-Operating
Temperature  +10°C to +60 °C
without optional
battery backup unit
 0°C to +40 °C with
optional battery
backup unit
 -30°C to +80 °C
without optional
battery backup unit
 0°C to +45 °C with
optional battery
backup unit
Humidity 5% to 90% RH,
noncondensing,
40 °C max,
27 °C max wet bulb,
16 hour dwells at
extreme
93% RH,
noncondensing,
40 °C max, 120 hours
Altitude 3200 m at 40 °C,
4 hour dwell
12,200 m at 0°C,
4 hour dwell
Vibration 0.25 G in all axes swept
for 5-500-5 Hz,
5 sweeps in all
at 1 octave/min
1.2 G in all axes swept
for 5-500-5 Hz,
5 sweeps in all
at 1 octave/min
Shock 5.5 G, 11 ms half-sine,
10± shocks in
x-, y-, and z-axes
33 G, 11 ms half-sine,
3± shocks in
x-, y-, and z-axes
Airflow At least 200 linear feet
per minute (LFPM)
N/A
Caution! Do not operate the 9750 Controller Card at any
time without proper cooling.
