LSI GS820 User Manual

ISTALLATIO
ISTALLATIO
27
27
four load sensors and press Enter to modify.
4. Use Up and Down to select the sensor type
“Imbalance sensor” and press Enter. Only one
imbalance sensor is required to calculate
imbalance for all four load sensors.
5. The ID can be left at 0, press Enter.
6. Press Enter to save any changes.
7. Press Exit to return to the operation display.
8. Confirm the imbalance factor limit and the
imbalance minimum limit in menu 6) S
YSTEM
LIMITS.
2.11c Slack Rope
Systems programmed for four load sensors and four
load sum indication can be programmed with a slack
rope sensor to warn against unwanted rope payout
when the load touches down.
Slack rope minimum limit. The slack rope
sensor compares the sum load to an adjustable
slack rope minimum limit. When the sum load
goes below the slack rope limit a slack rope
alarm is generated. The slack rope limit is
usually adjusted to less than the weight of all
rigging below the load sensors. The default
slack rope minimum limit for is 1000 (pounds or
kilograms depending on load display units).
Program the slack rope sensor.
1. Go to menu 4) INSTALLATION and select 4A1)
S
ENSOR LIST.
2. Enter the user password and press Enter.
3. Use Up and Down to advance to the next
available sensor position, usually following the
four load sensors, the sum load sensor and the
imbalance sensor. Press Enter to modify.
4. Use Up and Down to select the sensor type
“Slack rope sensor”. Only one slack rope
sensor is required to calculate slack rope for all
four load sensors.
5. The ID can be left at 0, press Enter.
6. Press Exit to return to the operation display.
7. Adjust the slack rope minimum limit in menu 6)
S
YSTEM LIMITS.
