Table: Lockout Codes (Continued)
Condition Code
Minimum slack rope . . . . . . . . . . . . . . . . 16384
Minimum list angle . . . . . . . . . . . . . . . . . 32768
Maximum list angle . . . . . . . . . . . . . . . . 65536
Minimum trim angle . . . . . . . . . . . . . . . 131072
Maximum trim rope . . . . . . . . . . . . . . . 262144
Table: Example № 1
Maximum radius. . . . . . . . . . . . . . . . . . . . . . 32
Minimum angle . . . . . . . . . . . . . . . . . . . . . . + 2
Default green wire trigger . . . . . . . . . . . . . = 34
Table: Example № 2
Maximum wind speed . . . . . . . . . . . . . . . . . . 1
Maximum angle . . . . . . . . . . . . . . . . . . . . . . . 4
Overload . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Maximum length. . . . . . . . . . . . . . . . . . . . . . 64
Two-block. . . . . . . . . . . . . . . . . . . . . . . . . . 128
Maximum tip height. . . . . . . . . . . . . . . . + 4096
Default white wire trigger . . . . . . . . . . . = 4301
Lockout relay inversion. By default the lockout
wires carry crane power supply voltage as long as
the display is in safe condition. When lockout is
triggered voltage is cut on the lockout wires linked
to the lockout condition.
Exceptionally the lockout relay can be inverted so
that lockout wires carry no voltage in safe condition
and carry crane power supply voltage when in a
triggered lockout condition. In this case if the
display fails, crane functions will not lockout.
1. In menu 4G), select 8) L
OCKOUT RELAY INVERTED
and press Enter to modify.
2. Use Up and Down to switch between “
YES” and
”NO” and press Enter to confirm any change.
3. Press Exit to return to the operation display.
2.1e Password Settings
Two levels of access are available: administrator
and user. The administrator password is required
to change the user password. In the event both the
administrator and the user passwords are lost
please call
LSI
LSI technical support. Menus
accessible from the operation display can be
individually protected by the user password.
1. Go to menu 4) I
NSTALLATION and select 4H)
PASSWORD SETTINGS.
2. Enter the administrator password and press
Enter.
3. Select 1) A
DMINISTRATOR PASSWORD and press
Enter to modify.
4. Use Up and Down to adjust the administrator
password. Press Enter to save any changes.
5. In menu 4G), select 2) U
SER PASSWORD and press
Enter to modify.
6. Use Up and Down to adjust the administrator
password. Press Enter to save any changes.
7. In menu 4G), select 3) T
ARE PROTECTED and
press Enter to modify.
8. Use Up and Down to switch between “
YES” and
“NO” and press Enter to save any changes.
9. Repeat steps 7 and 8 to adjust password
protection for each menu as required. Press
Enter at any time to save changes made. Press
Exit at any time to return to menu 4)
I
NSTALLATION. If there are any unsaved changes
the display will request confirmation: press
Enter to save before quitting or press Exit to
quit without saving.
WARNING! Inverting lockout relays will
allow crane operation in the event the GS820
display fails. Operating a crane without a
functioning anti-two-block system and load
and angle indication is dangerous and may
be against the law.
!
!
