- 17 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 1: Overview
Hardware Specifications
Number of ports (continued)  MegaRAID SAS 9260-8i RAID controller – Eight ports through two SFF-8087 x4 internal mini
SAS connectors
 MegaRAID SAS 9260CV-4i RAID controller – Four ports through one SFF-8087 x4 internal
mini SAS connector
 MegaRAID SAS 9260CV-8i RAID controller – Eight ports through two SFF-8087 x4 internal
mini SAS connectors
 MegaRAID SAS 9260DE-8i RAID controller – Eight ports through two SFF-8087 x4 internal
mini SAS connectors
 MegaRAID SAS 9260-16i RAID controller – Sixteen ports through four SFF-8087 x4 internal
mini SAS connectors
 MegaRAID SAS 9261-8i RAID controller – Eight ports through two SFF-8087 mini-SAS
4i connectors
 MegaRAID SAS 9265-8i RAID controller – Eight ports through two SFF-8087 x4 internal mini
SAS connectors
 MegaRAID SAS 9265CV-8i RAID controller – Eight ports through two SFF-8087 x4 internal
mini SAS connectors
 MegaRAID SAS 9266-4i RAID controller – Four ports through one SFF-8087 mini SAS 4i
internal connector
 MegaRAID SAS 9266-8i RAID controller – Eight ports through two SFF-8087 mini SAS 4i
internal connectors
 MegaRAID SAS 9270-8i RAID controller – Eight ports through two SFF-8087 mini SAS 4i
internal connectors
 MegaRAID SAS 9271-4i RAID controller – Four ports through one SFF-8087 mini-SAS 4i
internal connector
 MegaRAID SAS 9271-8i RAID controller – Eight internal SAS/SATA ports through two SFF-
8087 mini-SAS 4i internal connectors
 MegaRAID SAS 9271-8iCC RAID controller – Eight internal SAS/SATA ports through two SFF-
8087 mini-SAS 4i internal connectors
 MegaRAID SAS 9280-4i4e RAID controller – Four ports through one SFF-8087 x4 internal
mini SAS connector and four ports through one SFF-8088 x4 external mini SAS connector
 MegaRAID SAS 9280-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
 MegaRAID SAS 9280-16i4e RAID controller – Sixteen ports through four SFF-8087 x4
internal mini SAS connectors and four ports through one SFF-8088 x4 external mini
SAS connector
 MegaRAID SAS 9280-24i4e RAID controller – Twenty-four ports through six SFF-8087 x4
internal mini SAS connectors and four ports through one SFF-8088 x4 external mini
SAS connector
 MegaRAID SAS 9280DE-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
 MegaRAID SAS 9285-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
 MegaRAID SAS 9285CV-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
 MegaRAID SAS 9286-8e RAID controller – Eight ports through two SFF-8088 x4 external
mini SAS connectors
 MegaRAID SAS 9286CV-8e RAID controller – Eight internal SAS/SATA ports through two
SFF-8088 x4 mini external SAS connectors
 MegaRAID SAS 9286CV-8e RAID controller – Eight internal SAS/SATA ports through two
SFF-8088 x4 mini external SAS connectors
Data transfer rate Up to 6Gb/s per PHY
Table 2 6Gb/s MegaRAID SATA+SAS RAID Controller Features (Continued)
Specification
MegaRAID SAS 9240, SAS 9260, SAS 9261, SAS 9265, SAS 9266, SAS 9270, SAS 9271,
SAS 9280, SAS 9285, and SAS 9286 RAID Controllers

LSI MegaRAID SAS Specifications

General

RAID Levels	0, 1, 5
Ports	8
Form Factor	Low Profile
Operating Systems Supported	Windows, Linux, VMware
SAS Ports	8
BBU Support	Optional
Operating Temperature	0°C to 55°C
