LSI MegaRAID SAS User Manual

LSI Corporation
- 69 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 3: MegaRAID SAS RAID Controller Characteristics
Technical Specifications
 MegaRAID SAS 9286CV-8eCC RAID controller (model 25421)
 CacheVault Flash Module 01 (model CVFM01)
 CacheVault Flash Module 02 (model CVFM02)
 CacheVault Flash Module 03 (model CVFM03)
 CacheVault Power Module 01 (model CVPM01)
 CacheVault Power Module 02 (model CVPM02)
 LSI intelligent battery backup unit 07 (model 25034)
 LSI intelligent battery backup unit 08 (model 25343)
 LSI intelligent battery backup unit 09 (model 25407)
3.3.1 RAID Controller Specifications
The following table lists the specifications for the 6Gb/s MegaRAID SAS RAID controllers.
Table 21 RAID Controller Specifications
Specification
MegaRAID SAS 9240, SAS 9260, SAS 9261, SAS 9265, SAS 9266, SAS 9270,
SAS 9271, SAS 9280, SAS 9285, and SAS 9286 RAID Controllers
Processor
(PCI Express host controller to PCI secondary
I/O controller)
MegaRAID SAS 9240 RAID controllers: LSISAS2008 PCI Express-SAS/SATA I/O
Processor chip
MegaRAID SAS 9260, SAS 9261, and SAS 9280 RAID controllers: LSISAS2108 ROC
device with Integrated PowerPC processor
MegaRAID SAS 9260, SAS 9261, and SAS 9280 RAID controllers: LSISAS2208
RoC device
Part number  MegaRAID SAS 9240-4i RAID controller: 25083
 MegaRAID SAS 9240-8i RAID controller: 25091
 MegaRAID SAS 9260-4i RAID controller: 25121
 MegaRAID SAS 9260-8i RAID controller: 25121
 MegaRAID SAS 9260-16i RAID controller: 25243-06
 MegaRAID SAS 9260CV-4i RAID controller: 25377-00
 MegaRAID SAS 9260CV-8i RAID controller: 25377-00
 MegaRAID SAS 9260DE-8i RAID controller: 25121
 MegaRAID SAS 9261-8i RAID controller: 25239
 MegaRAID SAS 9265-8i RAID controller: 25366
 MegaRAID SAS 9265CV-8i RAID controller: 25422
 MegaRAID SAS 9266-4i RAID controller: 25413
 MegaRAID SAS 9266-8i RAID controller: 25413
 MegaRAID SAS 9270-8i RAID controller: 25422
 MegaRAID SAS 9271-4i RAID controller: 25413
 MegaRAID SAS 9271-8i RAID controller: 25413
 MegaRAID SAS 9271-8iCC RAID controller 25413
 MegaRAID SAS 9280-4i4e RAID controller: 25305
 MegaRAID SAS 9280-8e RAID controller: 25152
 MegaRAID SAS 9280DE-8e RAID controller: 25152
 MegaRAID SAS 9280-16i4e RAID controller: 25243-07
 MegaRAID SAS 9280-24i4e RAID controller: 25243-05
 MegaRAID SAS 9285-8e RAID controller: 25367
 MegaRAID SAS 9285CV-8e RAID controller: 25421
 MegaRAID SAS 9286-8e RAID controller: 25421

LSI MegaRAID SAS Specifications

General

RAID Levels	0, 1, 5
Ports	8
Form Factor	Low Profile
Operating Systems Supported	Windows, Linux, VMware
SAS Ports	8
BBU Support	Optional
Operating Temperature	0°C to 55°C
